[Applicable Standards] EN ANSI, UL, ASTM, ISTA international transportation standards
※Digital meter displays vibration frequency
※Synchronized noise-reducing belt drive, extremely low noise
※The sample clamping adopts guide rail type, which is easy and safe to operate.
※The base of the machine is made of heavy-duty channel steel with vibration-absorbing rubber pads, which is easy to install and runs smoothly without installing anchor screws.
※DC motor speed regulation, smooth operation and strong load capacity
※Rotary vibration (commonly known as horse racing), in line with European and American transportation standards
Technical Parameters：
|
Vibration Frequency |
100~300rpm |
|
Maximum Load |
200kg |
|
Amplitude |
25.4mm (1 inch) |
|
Effective Work Surface Size |
1200x1000mm |
|
Motor Power |
1HP (0.75kw) |
|
Table Body Size |
1200×1000×650 (mm) |
|
Timer |
0~99H99m |
|
Machine Weight |
100kg |
|
Display Frequency Accuracy |
1rpm |
|
Power Supply |
AC220V 10A |
