Equipment Summary:
This machine uses high-temperature to dry heat, it also can make micro-organisms oxidation, protein denaturation, to kill residual microorganisms in a certain period.
Applicable Industries:
It is widely used in paint, resins, plastics, printing and packaging, aluminum, adhesives, auto, cosmetics, metals, electronics, electroplating, medicine, etc..
Technical Parameter:
|
Model
|
6014-A
|
6014-B
|
6014-C
|
6014-D
|
6014-E
|
6014-F
|
|
Power
|
220V 50hz
|
380v 50hz
|
|
Temperature
|
Room temperature-300℃
|
|
Accuracy
|
±1
|
|
Fluctuation
|
±1%
|
±1%
|
±1%
|
±2%
|
±2%
|
±2%
|
|
Consume Power KW
|
0.8~1.6
|
0.8~1.6
|
1.6~2.4
|
2~3
|
3~4.8
|
4~6
|
|
Inside Size
(H*W*D)mm
|
350*350*350
|
450*350*350
|
550*450*550
|
750*600*500
|
1000*800*800
|
1000*1000*1000
|
|
Outside Size
(H*W*D)mm
|
590*660*520
|
690*760*520
|
790*870*640
|
1050*980*700
|
1300*1210*1000
|
1300*1420*1200
|
|
Package size (H*W*D)mm
|
710*740*600
|
810*840*600
|
910*950*720
|
1170*1060*780
|
1420*1290*1080
|
1420*1500*1280
|
|
Note: The inner box can be divided into mirror stainless steel plate and galvanized plate material
A inner box is galvanized plate material AS inner box is mirror stainless steel
|
Use Environment:
1.Working ambient temperature: 5℃～40℃ (average temperature ≤28℃ in 24 hours)
2.Ambient humidity: ≤85%
Main Function:
This machine can be used in drying glass, the thermal denaturation of sample and thermal induration experiment, eliminate specimen’s residual moisture,microbes in the vessels of the glass with dry heat sterilization, experiment of preheating,before heating food and chemical need to harden or softening experiment,ruled out moisture, extend the food in the harsh conditions of the preservation time, dry and heat resistance experiment the building materials, electronic components and dry,baking, disinfection, sterilization and material degeneration test.
Main Feature:
- The vertical drum wind drying oven is made of high qualified steel plate or mirror stainless steel,plastic spraying,studio shell double-layer tempered glass windows,beautiful modelling novel.
- ZL-6014 A vertical electric drum wind microcomputer intelligent control, temperature drying ovenoverheating protection,time settings, temperature, small fluctuations linear
- ZL-6014A series vertical drum wind drying oven instrument has tracking alarm function of mixing hot air circulation, the heat loss is small, the drum wind, heat can be independent operation.
Conform to the Standard:
Strictly refer to JB/T5520 “dry box technical conditions” national industry standard manufacturing.
Box Structure:
1.The inner liner of the box body is made of mirror stainless steel plate with argon arc welding, the outer liner of the box body is made of high quality steel plate with plastic spraying treatment, double-layer tempered glass observation window, the shape is beautiful and novel.
2.Hot air circulation system can run continuously under high temperature fan and special air duct composition, the temperature inside the working chamber is uniform.
3.With a large area of tempered glass observation window, for the observation of studio conditions.
4.Vertical electric blast drying oven microcomputer intelligent temperature control, overheating protection, time setting, good temperature control linearity, small fluctuation.
5.Vertical blast drying oven instrument with tracking alarm function stirring hot air circulation, small heat loss, blast, heating can be operated independently.
6.Temperature control alarm system, over the limit temperature is automatically interrupted to ensure the safe operation of the experiment does not happen accidentally.
