Standards:
GB / T3820.
Main Technical Indicators:
|
Test Thickness Range |
0.01mm ~ 20.00mm |
|
The Smallest Division value |
0.01mm |
|
Presser Foot Diameter And Area |
Φ11.28mm Φ50.48mm Φ56.42mm Φ112.84mm:100mm2, 2000mm2 ,2500mm2 ,10000mm2 |
|
Weight |
5cN, 10cN, 100cN, 400cN, 1000cN total of 5 species 5cN weight 1 only 10cN weight 2 only 100cN weight 2 only 400cN weight 1 only 1000cN weight 2 only |
|
Pressure Time |
10s, 30s |
|
Power |
AC220V ± 10% 50Hz |
|
Net Volume |
410mm × 160mm × 395mm |
|
Net Weight |
25kg |
