Application Place:
Applicable to airport entrances, customs clearance, electronic products factory, gymnasium, judicial court, court, viewing area, VIP venue, various nightclubs, bars, bars and other security inspection sites.
Features:
1.Digital I/O keyboard with safe channel control, LED light on display
2.High-brightness LCD screen operation
- Adjustable alarm volume
4.Power-on self-detection and automatic calibration
5.Last environmental memory and shutdown sound prompt
6.Adjustable sensitivity (300 levels),
three independent detection areas
7.10 minutes quick disassembly
8.All areas can be measured from head to toe
Technical Parameters:
1.Operating Voltage: AC 100v-240v
Power Consumption: <10W
2.All materials are made of ABS polycarbonate alloy — strong impact resistance and durable use.
(polycarbonate plate has good light transmittance, impact resistance, ultraviolet radiation resistance, mainly used in aerospace and automobile manufacturing industry)
3.Reserve battery (including ac adapter and
12V charging device)
4.Can be used for 36 hours in case of power failure (double battery 7000MA*2 total power 14000MA)
5.The design conforms to the standard :FAA, nilecj-0601.00
6.EMC Design
7.The total amount of the machine is 50kg
Environmental Design Parameters：
|
Channel Size
|
2150mm*810mm*600mm(Height * Width * Depth)
|
|
Overall Dimension
|
2300mm*980mm*600mm(Height * Width * Depth)
|
|
Package Size of Door Panel
|
1070mm*680mm*710mm(Height * Width * Depth)
|
|
Temperature
|
-20℃ to + 70℃ (-4f to + 158f)
|
|
Relative Humidity
|
95%
|
|
Protection Grade
|
IP55 UV protection
|
