Performance Characteristics:
★LCD display★Chinese and English menu★Shockproof★Rainproof★Anti-jamming★Remote control★High sensitivity★Precise detection position
Technical Parameters:
|
1. External Power Supply
|
90V – 230V 50/60Hz
|
|
2. Power Consumption
|
35W
|
|
3. Working Environment
|
-20℃─45℃
|
|
4. Total Transport Weight
|
About 75kg
|
|
5. Working Frequency
|
Self-adjusted according to the installation environment
|
|
6. Machine Weight
|
About 65kg
|
|
7. Dimensions
|
2220 (height) × 820 (width) × 610 (depth) (mm)
|
|
8. Channel Size
|
2000 (height) × 700 (width) × 610 (depth) (mm)
|
Technology Meets The Standard
The product complies with the following national and international recognized standards:
Electrical appliances are implemented according to the EN60950 safety standard.
Radiation is implemented according to EN50081-1 standard.
Anti-jamming is implemented according to EN50082-1 standard.
Strictly implement the current national standards for pass-through metal detectors.
Fully passed the ISO9001: 2000 quality management system certification.
Fully passed the EU CE certification.
Product Performance:
- Rainproof design: new rainproof design style, the top of the main box is fully closed, waterproof gaskets are added to the two sides, and the bottom is protected by a waterproof gauze cover to ensure normal work in the open air (rainy land) without shelter.
- Anti-vibration design: stand in the middle of the door and clap the door panels on both sides with your hands, the security door will not produce false alarms.
- Statistical counting function: it can display the number of passes and alarm times, the counting is accurate, and it will not be overcounted or undercounted.
- High-sensitivity design: The acceptance standard for similar products promulgated by the Ministry of Public Security is “detection of a one-yuan coin”. 5. 18-location detection: the detection area is divided into 18 locations, and suspicious objects can be accurately displayed in each area.
- 255-level sensitivity adjustment: The overall sensitivity of the equipment can be adjusted according to the needs, and the sensitivity of each partition can also be adjusted individually (reduce and increase product sensitivity) to meet the sensitivity needs of different places.
- Door body material: The face is made of paint sanding PVC material, the interior is made of high-quality fireproof board, and the four sides are inlaid aluminum alloy pillars, which are durable.
- Double column LED light display: LED lights are placed on both sides of the gate column, which can intuitively display the alarm location, and sound and light alarm at the same time.
- LCD panel display: The main panel of the door head is a 7-inch liquid crystal (LCD) display, with two menus in Chinese and English.
- Dual-adjustment probe design: it can be adjusted manually, or use the remote control to adjust the device parameters.
- Password protection function: After the parameters are set, a password can be set for protection, and unauthorized personnel cannot operate without a password.
- Multi-frequency screening technology: multiple groups of working frequencies can be set, so that when multiple devices work side by side, they will not interfere with each other.
- DSP digital intelligence technology: The system adopts advanced electromagnetic compatibility design, through the operation of DSP digital intelligence system on the sampling signal, and the filtering of environmental electromagnetic interference, the anti-electromagnetic interference ability of the equipment is enhanced.
- Environmentally friendly and harmless: no harm to pacemaker wearers, pregnant women, magnetic media, etc., and no slight negative effects.
Technical Support and Service:
- Product installation and technical guidance: deliver goods within Shenzhen, provide installation and operation guidance; provide telephone guidance services outside the urban area; provide 24-hour telephone service.
- From the date of sale of the product, if there is any quality problem (failure that cannot be ruled out) within one month, it will be responsible for free replacement, free warranty within two years, and lifetime maintenance.
Scope of Application:
Suitable for electronic hardware factories, jewelry stores, entertainment venues, airports, customs, government agencies, and various competition venues. Public security organs, prisons, detention centers, entertainment venues. Mining, coinage, electronics, hardware, jewelry. Other places that require security precautions.
