Features:
- 1.Design green and environmental protection: UWB pulse microwave reflection method and thermal conductivity method are adopted. No radiation setting is harmless to human body and items to be inspected. The detection method is environmentally friendly and safe.
- 2. Detection range: It can detect more than 30 kinds of various types of dangerous liquids, including gasoline, kerosene, diesel, hydrochloric acid, sulfuric acid, nitric acid, ether, diisopropyl ether, petroleum ether, acetaldehyde, ethylene glycol, nitrobenzene, Propylene oxide, n-heptane, pine perfume, acetone, benzene, toluene, xylene, dichloroethane, isopropanol, carbon disulfide, methanol, nitromethane, chloroform, n-hexane, etc. Corrosive liquids, even at very low concentrations of dilute sulfuric acid, dilute hydrochloric acid and dilute nitric acid, can be tested 100% accurately.
- 3.Fast detection speed: The non-metallic bottle liquid detection time is the fastest in the industry, with an average of 0.5 seconds, and the metal bottle liquid detection time averages 7.5 seconds.
- 4.Various alarm settings: The detection result is in two modes: indicator light alarm and sound alarm. The result is intuitive and easy to distinguish.
- 5.Detecting the bottom of the container: The only instrument that is detected through the bottom of the container, the tested container can be detected without leaving a lot of liquid.
Basic Parameters:
|
Dimensions
|
460mm (width) X367mm (deep) X260 mm (height)
|
|
Weight
|
≤14Kg
|
|
Power Consumption
|
10W
|
|
Power Supply
|
AC180-240V (50/60Hz)
|
|
Detection Bottle Temperature
|
5-35 ° C
|
|
Storage Temperature / Relative Humidity
|
-40℃ ~ +60℃ / 5% ~ 95% (no condensation)
|
|
Operating Temperature / Relative Humidity
|
15℃ ~ +35 ℃ / 5% ~ 95% (no condensation)
|
Technical Indicators:
- Applicable liquid packaging materials: capable of detecting packaging liquids of different materials such as iron, aluminum, plastic, glass and ceramics
- Detectable hazardous liquid categories: flammable, explosive, corrosive hazardous liquids
- Detectable volume size: ceramic jar, glass bottle, PET plastic bottle 30mm ≤ diameter ≤ 200mm;
Metal cans (iron, aluminum cans) diameter ≤ 80mm;
Metal tank / tank liquid volume ≥ 100ml, non-metallic container ≥ 100ml
- Detectable effective distance: 30mm from the bottom of the metal container, 60mm non-metallic container
- Dangerous liquid display: the indicator light is red and the buzzer sounds long
- Safe liquid display: the indicator light is green and accompanied by a short sound alarm
- Boot time: 2.3s, no need to warm up
- Self-checking function: It has self-checking function and self-checking time is 1.8 seconds.
- Automatic counting function: It can automatically calculate the number of detected objects.
- Authentication function: With authentication function.
- Human-machine interface check: The device man-machine interface provides a full Chinese interface and comes with a light source. The equipment user can adjust the equipment parameters through the keyboard according to the working environment.
- Detection method: the exclusive first detection method of the bottom of the bottle.
- Detectable liquid category: The general measurement mode and the strong acid and alkali mode can alarm the flammable or corrosive hazardous liquid in the 14.32 kinds of sealed containers such as 93# gasoline, hydrochloric acid, sulfuric acid and petroleum ether.
- Detection time: insulated container (plastic, glass, ceramic container): 1 second lead capacitor (aluminum can, iron can): 7.6 seconds
- Alarm mode: Sound/light alarm/LCD graphic display, alarm sound is turned off separately.
- Alarm reset: The device can be manually or automatically reset after an alarm occurs for the next test.
- Data storage check: liquid detection result storage and retrieval function, storage capacity 10000 times detection, and can export data by standard network interface or USB interface, which can be read and analyzed by PC upper software.
