The Characteristics and Scope of Use
1.Ultra-high sensitivity, stable performance, suitable for detecting all metals.
2.Alarm mode: sound and light synchronization alarm or silent vibration alarm, with headphone output function (optional headphones), the alarm volume can be changed according to the size of the target object.
3.Use battery, external charger function (charger optional), with low voltage warning function.
4.When the electric volume becomes low, the detection distance remains the same. Stable performance.
5.The enterprise through the ISO9001: 2008 quality management system certification
6.The product through the EU CE certification
7.The product conforms to the Ministry of Public Security security and police electronic products quality standards
Applications:
This product is mainly used in the relatively high requirements of government agencies, public security organs, procuratorates, courts, prisons, detention centers, customs, airports, stations, stadiums, exhibition venues, entertainment venues, large gatherings and other hardware, electronics, jewelry, military, minting and other factories or enterprises.
Technical Parameters
|
1.Circuit
|
transmitter / receiver automatically readjust. No need to manually adjust.
|
|
2.Detection Sensitivity
|
20MM diameter steel ball, detection distance of ≥ 9 cm
|
|
3.Alarm Mode
|
sound and light, vibration synchronization alarm, can be with headphone output function.
|
|
4.Power Supply
|
9-volt square battery (6F22ND battery), can be external charger function (charger optional)
|
|
5.Operating Frequency
|
95kHz
|
|
6.Sound Frequency
|
2kHz
|
|
7.Operating Current
|
less than 50MA
|
|
8.Operating Temperature
|
-5℃ to 45℃
|
|
9.Exterior Dimensions
|
48.3 * 8.7 * 4.1 cm
|
|
10.Net Weight
|
527g
|
|
11.Package Size
|
54 * 27 * 45 cm (20pcs/ctn, 15kg/ctn)
|
Operation Introduction:
1.When the metal is in working condition, swing the detector to scan people (or other detection objects) at a distance of about two inches. If the metal is detected. The machine will issue an alarm sound or silent vibration, and red light. No need to re-adjust after detection. Scan range is generally from one to two inches from the floor distance to detect objects.
2.Sound alarm operation, press the power switch forward, the detector detects metal, you will hear a clear alarm sound. Red alarm light will also continue to light up to indicate the detection of metal.
3.no sound vibration, slide the power switch backward to detect, in the detection of metal, metal detector handle will vibrate, and will not make a sound. Red alarm light will also continue to indicate the detection of metal.
Cautions:
Please do not affix a metal label (or any material that may cause the detector to false alarm) in the detection area of the detector. Doing so may lead to imbalance in the detection field, thus reducing the effectiveness of the scan.
