Thermal conductivity (or thermal resistance) is the main thermal performance of thermal insulation materials, and it is the main technical index to identify the thermal insulation properties of materials. In recent years, with the introduction of building energy conservation regulations, my country has paid more and more attention to building energy conservation. Therefore, it is very necessary to accurately measure this parameter. It is very important for the rational selection of materials.
Technical indicators:
|
1. Specimen specification |
300X300mm Thickness 10～45mm (preferably thickness 25mm) |
|
2. Cold plate temperature |
5℃～50℃ |
|
3. Hot plate temperature |
room temperature～80℃ |
|
4. Test accuracy |
≤2% |
|
5. Test repeatability |
<1% |
|
6. Power supply voltage |
AC 220V total power 2KW |
|
7. Use environment |
10-40℃ (recommended use environment is laboratory with air conditioner, temperature range: 25±5℃) |
|
8. Dimensions |
800 X 600 X 1600mm |
|
9. Weight of the whole machine |
215Kg |
Features:
It can be used for foam concrete and thermal insulation mortar to make standard samples for testing and testing using 300*300mm forming test molds
