The umbrella rain tester mainly simulates the climatic environment, which has a greater impact on product aging, color, and metal corrosion.As a result, the aging test is more and more valued by the rubber, plastic, chemical, automotive and other industries.The climate and environmental factors are many. Such as solar light, temperature, humidity, rain, etc., this test machine is an analog environmental test equipment for rain, which meets a number of test standards such as GB, CNS, ISO, ISO, UL, BS, etc.
Overview:
The umbrella rain tester mainly simulates the climatic environment, which has a greater impact on product aging, color, and metal corrosion.As a result, the aging test is more and more valued by the rubber, plastic, chemical, automotive and other industries.The climate and environmental factors are many. Such as solar light, temperature, humidity, rain, etc., this test machine is an analog environmental test equipment for rain, which meets a number of test standards such as GB, CNS, ISO, ISO, UL, BS, etc.
Technical parameters:
|
Timer |
LED timer, can switch between minutes and hours |
|
Taiwan Dongli gear miniature motor |
AC220V, 90W |
|
Umbrella rotation speed |
5 / r / min |
|
Maximum height of the whole machine |
3000mm |
|
Base diameter |
2000mm |
|
Nozzle to test piece distance |
800mm (adjustable) |
|
Maximum diameter of test piece |
1500mm |
|
Maximum height of test piece |
900mm |
|
Spray water |
soft tap water |
|
Standard water spray volume |
(3.6 ± 0.05) L / min |
|
Air pressure |
normal pressure |
|
Working voltage |
AC220V 50HZ |
|
Ambient temperatur |
0 ℃ ～ 40 ℃ |
|
Relative humidity |
<85% r.h |
|
Spraying range |
within Φ1.5m |
