Application:
Produced according to safety helmet GB/T2812-2006, GB 2811-2019、ECE、EN、ASTM、JIS、SNELLM2015、AS/NZS 2063, mainly used for safety helmet very high temperature pretreatment. It is widely used in special labor protection supplies supervision and inspection stations, construction science research institutes, construction engineering quality inspection stations, electric power departments and helmet production enterprises.
Feature:
1、Adopt multi-channel intelligent controller, which can automatically control the alignment.
2、The test time is preset, the test box and the head mold platform will be separated automatically after the test time arrives, and the head mold platform will drop to the initial position.
3、The temperature of each station can be set by itself, and the head mold automatically rises to the test box when it reaches the test temperature, and then stops automatically at the preset position.
4、Large size head mold platform and test box, can pre-process 1-4 helmets at a time.
5、Configuration of five-way temperature measurement system, respectively, the test box inside and inside the four head mold collection, independent unit independent collection and output.
6、Configuration of 5 sets of independent unit air circulation device to ensure that the test chamber and the internal temperature of the head mold meet the standard requirements.
7、Configuration of GB2812 1 #, the material is aluminum alloy head mold 4.
8、the test is completed, the stations automatically restore the initial state, the test is completed automatically alarm prompt, the test chamber residual temperature delayed exhaust.
Technical parameters:
|
Test Chamber Temperature |
Room temperature – 200°C, standard operating temperature 150±5°C |
|
Time of tests |
0-99 min, self-adjustable, 60±2 min standard |
|
Number of tests |
1-4 Tops |
|
Head temperature |
50℃±2℃ |
|
Test heads |
Wall thickness > 1.5mm, size GB2812 of 1#, material aluminium alloy, internal hollow |
|
Head temperature measurement points |
Distance from the midpoint of the head mould <40mm |
|
Instrument size |
870*710*1100mm |
|
Instrument power supply |
220V 50HZ 2.8KW |
Application Standard：
GB/T2812-2006, GB 2811-2007、ECE、EN、ASTM、JIS、SNELLM2015、AS/NZS 2063
Can be customized according to the above standards
