① using ARM technology, built-in Linux system. The user interface is simple and straightforward. Viscosity tests are quickly and easily performed through the creation of test programs and data analysis.
Viscosity measurement accuracy: Each range are automatically calibrated by computer, high precision, small error;
③ display rich: In addition to the viscosity (kinematic viscosity and kinematic viscosity), there are temperature, shear rate, shear stress, the measured value percentage of full scale (graphic display), range overflow alarm, automatic scanning, the current rotor speed Combination of the maximum measurement range, date, time and so on. And in the case of known density shows kinematic viscosity to meet the user’s different measurement requirements;
④ full-featured: time measurement, self-built 30 sets of test procedures, access to 30 sets of measurement data, real-time display viscosity curve, print data and curves;
⑤ front level: level adjustment intuitive and convenient;
⑥ stepless speed regulation: HRV1T series: 0.3-100 rpm, a total of 998 kinds of speed
⑦ shows the shear rate of the viscosity curve: you can set the scope of the shear rate, real-time display on the computer; can also display the time curve of viscosity
⑧ optional Pt100 temperature probe: temperature measurement range, from -20 to 300 ℃, temperature measurement accuracy of 0.1 ℃;
⑨ optional accessories rich: viscometer dedicated thermostat bath, thermostat Cup, printer, the standard viscosity of samples (standard silicone oil) and so on;
⑩ Chinese and English operating system.
The HDV1T series can measure a very large range, from 300mPa.S to 26000000, covering most of the sample. Widely used in paints, coatings, cosmetics, ink, pulp, food, oil, starch, solvent-based adhesives, latex, biochemical products and the need for high temperature melting, such as asphalt, paraffin, hot melt adhesive and other industries.
Parameter:
Control / Display : 5-inch color touch screen
Speed : (r / min) 0.3 – 100 CVT, a total of 97 speed optional
Measuring range: mPa.s 200-2600 million (measured below the lower limit of viscosity, the need to choose R1 rotor)
Rotor: Rv2 – Rv7 (6, standard); Rv1 (optional)
Sample amount: 500ml
Measurement error: (Newtonian liquid) ± 1%
Repeated error: (Newtonian liquid) ± 0.5%
Display shear should be: / Shear rate standard
Timing functions: standard
Viscosity curve: real-time display viscosity curve
Kinematic viscosity to enter the sample density
Temperature measurement function: standard temperature probe interface (need to match the temperature probe)
Automatic scanning function: automatically scan and recommend the rotor and the speed of the priority combination
Maximum measuring range: Automatic display of the selected combination of rotor and speed Measurable viscosity range
Self-built measurement procedures: can save up to 30 groups (including the rotor, speed, temperature, time, etc.)
Save measurement results: Up to 30 sets of data can be saved (including viscosity, temperature, rotor, speed, shear rate, shear stress, time, density, kinematic viscosity, etc.)
Print data, the curve can print (standard with a print interface, the need to buy a printer)
Data output interface: RS232
Thermostatic components: Options (including a variety of viscometer dedicated thermostat, thermostat cup,)
Working power supply: Wide voltage work (110V / 60Hz or 220V / 50Hz)
Overall dimensions: 300 × 300 × 450 (mm)
