Viscosity measurement range |
10-100000mPa.S (NDJ-1S, NDJ-5S): 20-2000000 mPa.S (NDJ-8S) |
|
Viscosity measurement accuracy |
± 2% (full scale) |
|
Viscosity measurement reproducibility |
± 5% (full scale) |
|
Viscosity Resolution |
1 mPa.S (0 rotor with a resolution of 0.1 mPa.S) |
|
Standard rotor Specifications |
1,2,3,4 four (0 No. rotor optional) |
|
Speed |
6,12,30,60 rev / min (NDJ-1S, NDJ-5S) Sidang: 0.3,0.6,1.5,3,6,12,30,60 rev / min (NDJ-8S) eight block |
|
Temperature measurement range |
-50 ~ 99 ℃ (optional semiconductor temperature sensor) |
|
Temperature measurement accuracy |
± 5 ℃ |
|
Temperature Resolution |
0.1 ℃ |
|
Communication Interface |
RS232C (NDJ-5S, NDJ-8S) |
|
Communication baud rate |
9600 |
|
Dimensions |
95 * 130 * 155 (not including chassis) |
|
Weight |
2kg (not including chassis) |
|
Viscosity measurement range |
10-100000mPa.S (NDJ-1S, NDJ-5S): 20-2000000 mPa.S (NDJ-8S) |
|
Viscosity measurement accuracy |
± 2% (full scale) |
|
Viscosity measurement reproducibility |
± 5% (full scale) |
|
Viscosity Resolution |
1 mPa.S (0 rotor with a resolution of 0.1 mPa.S) |
|
Standard rotor Specifications |
1,2,3,4 four (0 No. rotor optional) |
|
Speed |
6,12,30,60 rev / min (NDJ-1S, NDJ-5S) Sidang: 0.3,0.6,1.5,3,6,12,30,60 rev / min (NDJ-8S) eight block |
|
Temperature measurement range |
-50 ~ 99 ℃ (optional semiconductor temperature sensor) |
|
Temperature measurement accuracy |
± 5 ℃ |
|
Temperature Resolution |
0.1 ℃ |
|
Communication Interface |
RS232C (NDJ-5S, NDJ-8S) |
|
Communication baud rate |
9600 |
|
Dimensions |
95 * 130 * 155 (not including chassis) |
|
Weight |
2kg (not including chassis) |
