Technical parameters
|
Model |
204-1K |
204-2K |
204-5K |
204-10K |
204-20k |
204-50K |
204-100K |
|
Measuring range |
±1kgf ±1000gf ±9.8N ±2.2Lbf |
±2kgf ±2000gf ±19.6N ±4.4Lbf |
±5kgf ±5000gf ±49N ±11Lbf |
±10kgf
±98N ±22Lbf |
±20kgf
±196N ±44Lbf |
±50kgf
±490N ±110Lbf |
±100kgf
±980N ±220Lbf |
|
Resolution |
0.001kgf 1gf 0.01N 0.001Lbf |
0.001kgf 1gf 0.01N 0.001Lbf |
0.001kgf 1gf 0.01N 0.001Lbf |
0.001kgf
0.01N 0.001Lbf |
0.01kgf
0.1N 0.01Lbf |
0.01kgf
0.1N 0.01Lbf |
0.01kgf
0.1N 0.01Lbf |
|
Display |
four large liquid crystal, positive direction double display |
|
Accuracy |
grade 0.5 |
|
Precision |
±0.5%FS (range) ±1 digital peak |
|
Unit |
Kgf, gf, N, Lbf |
|
Measured value |
peak, instantaneous value |
|
Shutdown mode： |
Automatic shutdown or manual shutdown for 10 minutes |
|
Backlight |
Blue backlight |
|
Allow load |
150%F.s (beeping alarm when exceeding 110%F.s) |
|
Power supply |
2 # 5 batteries or 6V dc power supply |
|
Work environment |
No seismic source and corrosive medium around |
|
Working temperature |
0~40ºC |
|
Working humidity |
<80% |
|
Net weight |
390g |
|
Size |
211x80x36mm |
Accessories
|
Standard Accessories |
Electronic tensile gauge with standard parts Pull hook Plane probe Conical probe V groove probe V wedge probe Extension link :Double screw Double nut Operating instruction Portable case |
|
Optional accessory |
Power adapter |
