Performance characteristics：
1.Using the microprocessor to control the operation interface, it is highly intelligent, powerful and easy to use.
2.High-precision load cell to ensure measurement accuracy.
3.LCD screen display, optional Chinese or English interface, rich display content, easy to use.
4.The measurement data can be automatically counted, analyzed, displayed and printed.
5.With real-time calendar clock function, the test and calibration date and time can be printed in the test report.
6.With fault self-diagnosis function, it will automatically prompt for some abnormal phenomena in the test.
7.Parameter settings are automatically saved until reset.
8.With calibration function, display and print calibration results.
Technical Parameter
|
Measuring range |
Hardness 1~350N |
|
Resolution 0.1N |
|
|
Accuracy ±0.03Kg ±0.5% of maximum range |
|
|
Diameter 2.0~30.0mm |
|
|
Accuracy ±0.01mm |
|
|
Unit of measurement |
hardness N/Kg/Sc (optional) |
|
Diameter mm/inch (optional) |
|
|
Measuring method |
manual single piece / automatic continuous (the maximum number of measuring pieces is 160 pieces) / optional |
|
Display |
LCD display 4 rows x 8 columns Chinese characters or 8 rows x 16 columns English / optional |
